    850nm Multimode QSFP Optical Cable 3m Fiber Optical Transceiver Module

    Ask Lasest Price
    Brand Name : Fujioptic
    Model Number : 40G QSFP-AOC
    Certification : RoHS 6 compliant
    Price : negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 10,000 pcs per month
    Delivery Time : 5~7 work days
    • Product Details
    • Company Profile

    850nm Multimode QSFP Optical Cable 3m Fiber Optical Transceiver Module

    40G AOC QSFP+ 850nm multimode 3m Fiber Optical Transceiver Module

    Product Description

    QSFP + Active Optical Cables (AOCs) are active optical cables of the QSFP + interface. The module has a photoelectric conversion device inside to convert the electrical signals into optical signals and transmit distances up to 100 meters. The products have four channels, each channel transmission rate up to 10Gb / s, rate of 40Gb / s. Its low power consumption, low bit error rate, easy to manage, high-performance features are widely used in short distance high-speed connection such as 10 Gigabit Ethernet, 10 Gigabit switches, 10 Gigabit servers, supercomputers, cloud computing and cloud storage networks.


    Features

    • Transmission data rate up to 10.3Gbit/s per channel

    • compliant with QSFP + MSA &SFF-8436 standard

    • Hot pluggable electrical interface

    • Differential AC-coupled high speed data interface

    • Multi-mode optical fibre cable of up to 100m

    • 4 channels 850nm VCSEL array

    • 4 channels PIN photo detector array

    • Supports serial ID functionality thru EEPROM

    • Management Interface and digital diagnostic

    • Low power consumption

    • 3.3V power supply voltage

    • Operating case temperature 0°C to +70°C

    • RoHS compliant


    Application

    • 10Gbs ~ 40Gbs of Ethernet

    • data storage and communications industry

    • Server and data storage devices

    • Switch / router / HBA and so on

    • Data center and in-rack connections
